5 Reasons to Combine Laser Diffraction Particle Sizing and Image Analysis

Particle size is by far one of the most important physical properties of particulate samples. The measurement of particle size distribution is routinely carried out across a wide range of industries for mainly two reasons; to better understand how particle size will affect their product performance and to optimise and control the quality of products and processes during manufacturing.

In addition to particle size, the shape or morphological surface properties of the particles can be equally as important or even interrelated eg. surface area and particle size. The size and shape of a particle can influence a variety of material properties. From dissolution rates of tablets, stability of paints, the texture of foods and coatings, to the flowability and packing density of powders, understanding particle size and shape can be critical when designing a product for a particular purpose or behaviour.

Why measure particle size using laser diffraction?

Laser diffraction technology for routine particle size analysis remains the method of choice across a diverse range of industrial sectors.  The speed and ease of use of this technology and the wide dynamic range (nm to mm)1 give users access to quick, reliable particle size data with minimal effort.

Laser diffraction is a non-destructive ensemble technique, meaning it calculates particle size distribution for the whole sample rather than building up a size distribution from measurements of individual particles. A sample, dispersed either in solution or fed dry which is passed through a collimated laser beam, scatters light over a range of angles. Large particles generate a high scattering intensity at relatively narrow angles to the incident beam, while smaller particles produce a lower intensity signal but at much wider angles. Laser diffraction analysers like the Mastersizer 3000 record the angular dependence of the intensity of light scattered by a sample, using an array of detectors. The range of angles over which measurements are made directly relates to the particle size range which can be determined in a single measurement2

However, particles are 3-dimensional objects, and unless they are perfect spheres (e.g. emulsions or bubbles), they cannot be fully described by a single dimension such as a radius or diameter3. Therefore, to simplify the measurement process particle size is defined using the concept of equivalent spheres. The equivalent sphere concept works very well for regular-shaped particles, but for particles that are shaped like needles or plates, the size in at least one dimension can differ significantly from that of the other dimensions.

For this reason, many groups also employ low-cost sieve analysis to evaluate the large particle content. However, in addition to being slow and manually intensive, sieving lacks sensitivity at the fine fraction of the distribution, particularly at < 38 µm which is known as the sub-sieve size region4. Excessive fines in this size range tend to cause attraction or bridging of particles and are often combined with humidity or sticking issues. Wet sieving may help, but screen blocking is still common especially in smaller sizes.  Laser diffraction using wet or dry dispersion methods overcomes these issues and enables faster, simpler analysis with better resolution and control of agglomerates.

How can imaging help measure particle size more accurately?

Imaging allows users to visually see the particles to determine particle size and shape and is complementary to laser diffraction particle sizing, allowing more data to be collected and measured.

The Hydro Insight is a dynamic imaging tool that sits alongside the Mastersizer 3000 particle size analyser. It provides real-time images of individual particles as well as quantitative data on particle shape at the same time as laser diffraction size measurements. Particles dispersed by the Mastersizer 3000’s wet accessories flow through the Hydro Insight and are then photographed by a high-resolution digital camera at up to 127 frames per second. The camera takes images of the suspended particles in the analysis cell, converts them to a digital format, and sends the information to the software for final analysis in real-time. Individual particle images are viewed directly and captured as image files for post-run processing. More than 30 size and shape metrics available such as circularity, ellipticity, opacity, mean diameter, and aspect ratio allows the user to understand how the combination of particle size and shape affects material behaviour.

Adding the Hydro Insight to your Mastersizer 3000, combines shape data with size data to enable the following benefits:

#1 Gain a deeper understanding of why materials behave the way they do

Hydro Insight provides real-time images of liquid dispersions of individual particles to provide quantitative data on particle shape. Circularity and aspect ratio (width and length) can be used to distinguish between particles that have regular symmetry, such as spheres or cubes, and particles with different dimensions along one axis, such as needle shapes. Other shape parameters that can be used to characterise particle form include elongation and roundness. This plays a significant role in applications such as powder processes where size and shape can influence powder flowability/ blending properties, cohesion/ formation of agglomerates, tableting/ compaction behaviour, porosity/ reactivity, and even health and safety. When assessing pharmaceutical drug products the size and shape of particles can influence drug delivery within the body, dissolution behaviour, bioavailability, and drug efficacy.

#2 Speed up method development

When setting up a method to measure particle size using laser diffraction, achieving optimal dispersion is important to prevent agglomerates and to ensure the reproducibility of results. This can involve multiple steps from varying the dispersant type or amount of surfactant to the amount of mechanical mixing or ultrasound needed. By combining size analysis with imaging, particles can be seen live in a liquid and any agglomerates that form can quickly be identified and dispersed using optimal conditions. Users can see their dispersion as they develop laser diffraction methods, saving time for other projects.

#3 Build confidence in product quality

Laser diffraction is an ensemble technique able to measure particle size and particle size distribution for a wide range of samples over a wide dynamic range. However, for materials that require narrow polydispersity, the presence of just a few large or outlying particles can make a big difference to their performance. Large particles can block printing nozzles or cause imperfections in coatings or even be a source of immunogenicity when developing pharmaceutical drugs. Adding the Hydro Insight to the Mastersizer 3000 provides images of individual particles and gives a number-based particle size distribution, so it becomes sensitive to even small numbers of oversized particles leading to enhanced resolution.

#4 Quickly troubleshoot

Laser diffraction offers a simple, fast, and reproducible technique to measure particle size reliably; however, samples can sometimes present results that are unexpected, contain artifacts or simply be “out of spec”. Looking at your material on a microscope often needs a different sample preparation method and that can make the picture more complicated.

By adding imaging to laser diffraction workflows, the process of troubleshooting can be automated and therefore speed up analytical processes. With Hydro Insight, any anomalies in results can be assessed to determine whether they were caused by oversized particles, agglomerates, bubbles, or something else.

#5 Faster method transfer

Sieving is one of the oldest and simplest techniques for separating particles based on their size. However, the time it takes to obtain accurate results, the poor resolution, and problems associated with particle agglomeration and sieve blockage, have seen sieving being replaced in most industries with laser diffraction. Laser diffraction and sieving can provide similar results when characterising spherical or semi-spherical particles, however, differences can be observed for non-spherical particles because each technique measures different particle properties. Laser diffraction measures light scattering from a group of particles and reports size as a volume distribution of spheres that would produce the recorded pattern. In comparison to sieving, a mixture of size, shape, and density generates a weight distribution. Therefore using sieving, an elongated particle will be reported using the smaller dimension and will appear smaller when compared to laser diffraction results.

The Hydro Insight provides a window or a set of eyes into the Mastersizer. It records thumbnail images of a dispersion of particles and measures quantitative particle shape data. It can report different size parameters for irregular particles such as particle width and elongation data that may correlate better with sieve analysis and thus simplify the transfer process from sieves to laser diffraction.

Laser diffraction provides fast, reproducible particle size data for a range of applications. Image analysis is often used in combination with laser diffraction to provide a further understanding of how materials behave as well as being an orthogonal technique that helps with method validation.

So why choose the MASTERSIZER 3000 with the Hydro Insight?

The MALVERN MASTERSIZER 3000 system has a unique, compact design that uses laser diffraction to measure particle size distribution. The Hydro Insight sits alongside the Mastersizer 3000 and provides real-time images of particles, as well as quantitative particle shape data. This enables users to gain a deeper understanding of their products for easier troubleshooting and quicker method development.  Learn more about the Malvern Mastersizer 3000 and Hydro Insight system, speak to ATA Scientific today.

Different Methods of Particle Size Measurement

Particle size analysis can seem a complex and intricate area. The thought of attempting to measure and draw conclusions about microscopically small particles can seem incredibly confusing and the techniques used to measure particles can perhaps seem daunting. Particle size analysers are of great use in achieving such measurements and techniques such as laser diffraction assist us to understand more about the properties of materials.

However, in order to understand some of the higher level concepts related to this area, it is necessary to have a sound grasp of the concepts that inform results.

Mean, median and mode

These three terms are too often confused and thought to mean the same thing. Far from being one and the same, these terms require definition:

Mean – Mean relates to the arithmetic average of the data.

Median – When concerned with particles, median is the value of the particle size that precisely divides the population into two halves. This means that there is 50% of the population above and 50% of the population below the value.

Mode – Mode defines the most common value in a frequency distribution. This also corresponds to the highest point of the frequency curve.

Common methods of particle size measurement

Because different dimensions of the particle are measured when different techniques are used, different results are obtained. Of the different methods of measurement, each has its own advantages and disadvantages.


While this is an old technique, it has the advantage of being cheap and particularly useful for the measurement of large particles. In industries such as mining, this can be particularly useful.

The main disadvantages associated with this technique include: it is not possible to measure sprays or emulsions and measurement of dry powders is also difficult when particles become small. Wet sieving can help to overcome this problem, but it is then very difficult to reproduce results. Materials such as clay, which are cohesive and agglomerated, are also difficult to measure.

As particles tend to orientate themselves through the sieve, operating methods and measurement times need to be standardised if accurate and meaningful results are to be obtained.


This has been a common method used (historically) in clay and ceramics industries.

There are two main problems with this process: the density of the material is needed and so it is not useful for determining particle size of emulsions where the material does not settle or for dense materials where the material settles quickly. Samples containing components of mixed density can not be accurately resolved. Measurement of small particles is very slow and therefore the process of repeating testing can be tedious.

Electrozone testing

This technique is very good for measuring red blood cells, but for real, industrial materials there are quite a few problems. It is very difficult to measure emulsions and dry powders and it is impossible to measure sprays. It is necessary to measure in an electrolyte and the required calibration standards are expensive.

Laser Diffraction

This is an often favoured technique that is considered to be one of the most accurate and reliable. It has a number of important advantages:

  • It is very flexible and can measure all types of particles (powders, emulsions, suspensions and sprays)
  • It is very rapid (answers can be produced in less than sixty seconds)
  • It offers an absolute method of particle analysis that is grounded in scientific principles and makes it possible for measurements to be taken without the need to calibrate any instrument against the standard
  • The technique provides a very wide and dynamic range
  • It is possible to measure an entire sample
  • The technique is highly repeatable.

Combine technique with instrument

The technique used to measure particle size will depend on the material being analysed, and the instrument used should be one of the highest quality. ATA Scientific is a trusted brand selling a range of scientific instruments suited to measuring particle size. Contact us today to find the right instrument for you.
