Malvern Zetasizer Ultra
The Zetasizer Ultra, the most advanced light scattering system, delivers enhanced resolution, speed and ease-of-use for the measurement of particle and molecular size, particle charge and particle concentration.
Manufacturer | Malvern Panalytical |
---|---|
Product Series | Malvern Zetasizer |
Measurement principle | Dynamic Light Scattering, Multi-Angle Dynamic Light Scattering (MADLS) |
Application | Molecular Weight & Size, Nano Particle Size, Protein Crystallisation, Zeta Potential |
Size range | 0.3 nm - 10 μm (diameter) |
Measurement angle | 173°, 13°, 90° |

Malvern Zetasizer Pro
The Zetasizer Pro is the most versatile system for the measurement of particle and molecular size and electrophoretic mobility and zeta potential of nanoparticles.
Manufacturer | Malvern Panalytical |
---|---|
Product Series | Malvern Zetasizer |
Measurement principle | Dynamic Light Scattering |
Application | Molecular Weight & Size, Nano Particle Size, Protein Crystallisation |
Size range | 0.3 nm - 10 μm (diameter) |
Measurement angle | 173°, 13° |

Malvern Zetasizer Lab
Zetasizer Lab is the entry-level particle size and zeta potential analyser with enhanced capabilities while also being cost-effective.
Manufacturer | Malvern Panalytical |
---|---|
Product Series | Malvern Zetasizer |
Measurement principle | Dynamic Light Scattering |
Application | Molecular Weight & Size, Nano Particle Size, Protein Crystallisation, Zeta Potential |
Size range | 0.3 nm - 10 μm (diameter) |
Measurement angle | 90° |

Fluidity ONE-W Serum
Fluidity ONE-W Serum can accurately detect and characterise the binding affinity of antibodies to virus proteins directly in human serum.
Manufacturer | Fluidic Analytics |
---|---|
Product Series | Fluidity One |
Measurement principle | Microfluidic Diffusional Sizing (MDS) |
Application | Biomolecular Interactions, Nano Particle Size, Protein Conformation, Protein Interactions & Binding Affinity |
Size range (hydrodynamic radius) | 1 - 20 nm |
Molecular Weight range | 1.4 kDa - 14 MDa |

Fluidity ONE-W
Fluidity ONE-W allows accurate and detailed protein interactions analysis under near-native conditions with an easy-to-use workflow.
Manufacturer | Fluidic Analytics |
---|---|
Product Series | Fluidity One |
Measurement principle | Microfluidic Diffusional Sizing (MDS) |
Application | Biomolecular Interactions, Nano Particle Size, Protein Conformation, Protein Interactions & Binding Affinity |
Size range (hydrodynamic radius) | 1 - 20 nm |
Molecular Weight range | 1.4 kDa - 14 MDa |

Malvern Mastersizer 3000
The Malvern Mastersizer 3000 is a compact optical system that uses laser diffraction to measure particle size distribution for both wet and dry dispersions with minimum effort.
Manufacturer | Malvern Panalytical |
---|---|
Product Series | Malvern Mastersizer |
Measurement principle | Laser Diffraction |
Application | Particle Size |
Particle size range | 10nm to 3500µm |
Typical measurement time | >10sec |

Malvern Mastersizer 3000E
The Malvern Mastersizer 3000E provides a cost-effective, entry level particle sizing system that uses laser diffraction to measure the particle size distribution for both wet and dry dispersions with minimum effort.The Mastersizer 3000E can be upgraded as required.
Manufacturer | Malvern Panalytical |
---|---|
Product Series | Malvern Mastersizer |
Measurement principle | Laser Diffraction |
Application | Particle Size |
Particle size range | 0.1 to 1000µm |
Typical measurement time: | <10sec |

Malvern Spraytec
The Malvern Spraytec system is specifically designed for spray characterisation and provides real-time size distribution of spray droplets and aerosols.
Manufacturer | Malvern Panalytical |
---|---|
Product Series | Malvern Spraytec |
Measurement principle | Laser Diffraction |
Application | Aerosols - Sprays sizing |
Particle size range | 0.1 to 900µm and 2 to 2000µm |
Accuracy | Better than 1% |

Malvern NanoSight NS300
Malvern NanoSight NS300 provides high resolution size distribution and concentration measurements for individual nanoparticles while a fluorescence mode allows differentiation of fluorescing particles.
Manufacturer | Malvern Panalytical |
---|---|
Product Series | Malvern NanoSight |
Measurement principle | Nano Particle Tracking |
Application | Exosome Tracking, Nano Particle Size, Nano Particle Tracking & Count |
Particle size range | 10nm to 2000nm |
Laser wavelengths | 405nm (Violet), 488nm (Blue), 532nm (Green), 642nm (Red) |

Malvern Insitec Spray
Malvern Insitec Spray delivers real-time particle size measurement of sprays and aerosols in the process environment.
Manufacturer | Malvern Panalytical |
---|---|
Product Series | Malvern Insitec |
Measurement principle | Laser Diffraction |
Application | Aerosols - Sprays sizing |
Particle size range | 0.1µm to 2500µm |
Particle Size Distribution | Online |
Customer Installations

UWS, Advanced Materials Characterisation Facility (AMCF) have installed their new bench-top Phenom XL Scanning Electron Microscope (SEM).
Phenom XL Desktop SEM

The UWS through collaboration with Phenom-World BV, and ATA Scientific has been able to secure a 2 year placement of the bench-top Scanning Electron Microscope (Phenom SEM)
Phenom GSR SEM

UNSW, School of Chemical Engineering has installed their new KSV NIMA Langmuir-Blodgett Trough
Biolin-KSV NIMA LB Trough

LaTrobe University, School of Molecular Sciences, have installed their new NTA system to investigate extracellular vesicles (exosomes, microvesicles)
Malvern NanoSight NS300
Particle Science
Particle science is a branch of science that studies the elementary constituents of matter and the interactions between them. Modern particle science research is focused on particles from a few nanometres to over 3000 microns in size.
Particle size analysis is used for quality control in many different industries. In just about every industry where milling or grinding is required, particle size is a critical factor in determining the efficiency of manufacturing processes and performance of the final product.
The physical properties of particulate materials can influence a wide range of material behaviours. For example, reaction and dissolution rates, how easily ingredients flow and mix, or compressibility and abrasivity. From a manufacturing and development perspective, some of the most important physical properties to measure are:
- Particle size
- Particle shape
- Surface properties
- Mechanical properties
- Change properties
- Microstructure.
Techniques used in particle science
Techniques used for particle science measurement include:
Laser diffraction
Laser diffraction is a widely used particle sizing technique for materials ranging from tens of nanometres up to several millimetres in size. The main reasons for its success are its wide dynamic range, fast results, repeatability, instant feedback, high sample throughput and easy verification using standard reference materials. Laser diffraction can be used to measure dry powders, aerosols, liquid suspensions and emulsions.
Dynamic light scattering (DLS)
DLS is a non-invasive, well-established technique for measuring the size and distribution of molecules and particles lower than 1nm. Typical applications of DLS include the characterisation of particles, emulsions or molecules that have been dispersed or dissolved in a liquid. Particles are illuminated by a laser beam and scatter the light as a result of Brownian motion. Since the Brownian motion is related to the particle size, by measuring the scattered light the particle size can be calculated.
Multi-angle dynamic light scattering (MADLS)
MADLS offers improvements in particle sizing resolution, sensitivity and accuracy when compared to traditional single angle DLS. By combining sequentially-collected measurement data from three measurement angles it delivers improvements in resolution, typically from 3:1 to 2:1. MADLS also enables calibration-free particle concentration analysis for a wide range of materials, resolving the individual concentrations of different size populations to provide even greater insight into liquid samples.
Nanoparticle tracking analysis (NTA)
NTA is a unique and patented technology that enables rapid and simultaneous multi-parameter analysis and characterisation of many different types of nanoscale particles. NanoSight enables the ability to visualise individual particles in solution, then analyse for size and count/concentration, under scatter and fluorescence mode.
Image analysis
Image analysis is a set of techniques that permit the investigator to obtain quantitative information from morphological preparations. When used properly, it’s a powerful tool that’s capable of providing meaningful data. With this method, microscope optics and a charge-coupled device (CCD) camera magnify and capture particle images, which are then counted and measured. The main applications of image analysis include measuring particle shape and the detection of sample contamination. Image analysis systems are generally used in the range of 0.5 – 1000 microns.
Particle science instruments
ATA Scientific provides instruments, service and expert advice in the field of particle science, and we represent a group of highly regarded international companies. We support a range of particle science analytical equipment for research and other applications. Instruments include:
- Malvern Zetasizer Ultra
- Malvern Mastersizer 3000
- Malvern Spraytec
- Malvern Insitec Spray
- Malvern NanoSight NS300
Our team has an extensive range of skills and experience in analytical technologies, and we share that with you through ongoing assistance and advice. Need help finding the right analytical equipment for your application? Call us now on 02 9541 3500 or request a free consultation.
